LitTB-502-C Fiber Terminal Box

Model: 03025KEY

Highlights

LitTB-502-C is a compact fiber terminal box for using at the final fiber termination point. It has an attractive mechanical protective design inside the customer premises. It is used to terminate the internal fiber cable in the customer end to an optical network unit (ONU) point which is ready to connect multi-dwelling unit (MDU) and single dwelling unit (SDU).

Description

LitTB‑502‑C Fiber Terminal Box

Product Overview
The LitTB‑502‑C is a compact indoor fiber terminal box deployed at the final fiber termination point for customer‑premises fiber termination. It delivers robust mechanical protection for indoor fiber cabling inside subscriber premises, serving to terminate indoor customer‑side fiber cables toward the ONU connection point. This unit fits both multi‑dwelling unit (MDU) and single‑dwelling unit (SDU) FTTH scenarios, and must be used paired with corresponding adapters for complete fiber termination functionality.

Key Features
• Supports Max. 2 SC adapters
• Maximum 2‑fiber (2F) splicing capacity
• Integrated built‑in cable management structure
• Dual termination options: indoor cable termination via field‑installable connectors, or fusion splicing with internal pigtails for adapter interconnection
• Compact slim form factor for indoor wall‑mount deployment
• IP30 ingress protection rating for indoor environment safety

Fiber Splicing & Management
The LitTB‑502‑C terminal box supports up to 2‑fiber splicing, available in 1F and 2F box variants. Internal routing guides organize fiber bending and looping to safeguard splice points and simplify on‑site installation and routine maintenance.
• Splice Capacity: Max. 2F total
• Adapter Compatibility: Max. 2 SC adapters
• Supported Cables: 2 pcs 2×3 mm figure‑8 cable (0.3 m); or 2 pcs Φ0.9 mm pigtail (1 m)

Physical & Protection Performance
The enclosure provides IP30 ingress protection for indoor use, shielding internal fiber components against dust and solid‑object intrusion. The housing has dedicated cable entrance holes, a removable box cover, and mounting provisions for wall installation.
• Ingress Protection Grade: IP30
• Dimensions (H × W × D): 80 mm × 80 mm × 15 mm (±2 mm)
• Color: White
• Mounting Type: Indoor wall‑mount

Applications
Suitable for:
• FTTH / FTTx indoor customer‑premises termination
• MDU and SDU subscriber‑end fiber termination
• Indoor wall‑mount termination points connecting to ONU equipment
• Indoor final‑point fiber cable termination with SC adapter interfaces

Construction
• Dimensions: 80 mm × 80 mm × 15 mm (±2 mm)
• Color: White
• Structure: Compact wall‑mount indoor terminal box, available in 1‑fiber and 2‑fiber configurations
• Standard accessories: Wall‑mount kit (2 self‑tapping screws, 2 plastic expansion sleeves)
• Optional accessories: Fiber splice protective sleeves, nylon cable ties, SC adapters, Φ0.9 mm SC/APC pigtails

Network Reliability
The LitTB‑502‑C compact fiber terminal box integrates solid mechanical housing, built‑in cable routing, dual termination modes, and IP30 indoor protection. It delivers stable physical protection for subscriber‑side fiber termination, enabling neat, reliable fiber hand‑off between building‑internal cabling and customer ONU devices for FTTx access networks.

Specification

BASIC INFORMATION  Value
Product Series LitTB-500 series
Model Number LitTB-502C
Material ABS
Color White
Dimension 80mm x 80mm x 15mm (+2mm)
Net Weight 30g
IP Protection Level IP30
Operation Temperature -5℃~+45℃
Place of Origin China
Warranty Time 1 year
Key Specifications Value
Fiber Termination Box Type Indoor
Adapter Capacity 2 SC adapter





SHIPPING INFORMATION  Value
MOQ 500 pcs
Delivery Time 45 calendar day
